ABB Bailey IMSED01 Event Sequencer Digital Input Module Detailed Overview

Product Introduction

The ABB Bailey IMSED01 is a digital input module designed for event sequencing and process control within the Bailey automation system. It is part of the Bailey Network 90 series, providing reliable and accurate digital input processing. The module allows for the collection and sequencing of event-based digital signals in complex industrial automation systems.

The IMSED01 is engineered to manage a large number of input events, providing precise time-stamping and sequencing information for every input received. This makes it ideal for systems that require high reliability, such as those in the oil and gas, chemical, power generation, and manufacturing sectors. It can handle multiple event types while ensuring that safety protocols and operational parameters are strictly followed.

This module is optimized for ease of use and integration into existing systems, providing a high level of system redundancy, fault tolerance, and diagnostic capabilities to ensure that no event is overlooked. With a compact design and robust performance, the IMSED01 is a reliable choice for monitoring critical input signals in modern industrial control systems.

Product Specifications

Product Applications

The ABB Bailey IMSED01 is a versatile and robust event sequencer digital input module, designed to process and manage digital inputs in real-time applications. Its primary uses include:

• Oil & Gas: In upstream, midstream, and downstream operations, managing real-time events such as pressure, flow, and level sensing in hazardous environments.

• Power Generation: For monitoring and sequencing critical events, such as turbine control, safety systems, and emergency shutdown sequences in power plants.

• Chemical & Petrochemical: To handle multiple input signals and sequence events associated with critical chemical processes, ensuring safe operation and compliance with industry standards.

• Manufacturing and Automation: Used in automated production lines to monitor machine states, safety interlocks, and event-driven processes, maintaining smooth production flow and system integrity.

• Water and Wastewater Treatment: For managing event-based digital inputs in water treatment plants, controlling processes such as flow regulation, chemical dosing, and filtration operations.

Product Advantages

1. High-Speed Event Processing: The IMSED01 provides fast response times of < 1 ms, enabling near-instantaneous reaction to digital input events, which is essential in safety-critical applications.

2. Reliable and Precise Sequencing: With 16 digital input channels, this module can manage and sequence a large number of events, ensuring that inputs are captured in real-time and processed accurately for sequential control.

3. Compact and Robust Design: Its 100 x 120 x 40 mm form factor and 0.281 kg weight make it ideal for systems with space constraints while maintaining a high level of robustness to withstand industrial environments.

4. Galvanic Isolation: Each input channel is galvanically isolated, protecting sensitive components from electrical noise and ensuring the safety of the system in case of faults.

5. Wide Temperature Range: The module operates within a temperature range of -20°C to +60°C, making it suitable for use in both indoor and outdoor industrial environments.

6. Easy Integration with Other Systems: Supports MODBUS communication, ensuring compatibility with a wide range of existing systems and allowing easy integration into complex automation setups.

7. Certifications: The IMSED01 is CE, UL, and IEC 61508 certified, meeting international safety and quality standards, ensuring reliable operation in critical applications.

8. Low Power Consumption: With a power requirement of just 24 V DC, it ensures efficient operation without consuming excessive energy, contributing to overall system cost savings.

Brand Information

• Brand: ABB Bailey

• Product Series: Bailey Network 90 Series

• Type: Event Sequencer Digital Input Module

• Industry Focus: Oil & Gas, Power Generation, Chemical, Manufacturing, Water Treatment

Recommended Models: Bailey Network 90 Series and Related
