Product Description
The ABB Bailey IMDSI15 is a digital input slave module designed to integrate seamlessly within ABB Bailey’s distributed control systems (DCS). This module is a key component in the Bailey INFI 90 series and allows for the efficient and reliable collection of digital input signals from field devices such as sensors, switches, and safety interlocks.
The IMDSI15 module supports 24 V DC input signals and provides a robust interface to handle digital signals in industrial automation systems. It has 16 input channels, with electrical isolation for protection against electrical surges, making it highly suitable for use in industries where system reliability is crucial.
The module’s high-performance design ensures accurate signal detection, offering high-speed response times and ensuring that control systems react in real-time to changes in digital inputs.
Product Specifications
| Specification |
Value |
| Dimensions |
220 x 100 x 40 mm |
| Weight |
0.6 kg |
| Input Type |
Digital Input (24 V DC) |
| Number of Channels |
16 Channels |
| Input Voltage |
24 V DC |
| Power Consumption |
4 W |
| Mounting |
DIN Rail |
| Electrical Isolation |
Yes |
| Temperature Range |
-25°C to 60°C |
Applications
The ABB Bailey IMDSI15 module is widely applicable in a variety of industrial sectors due to its flexibility, reliability, and high-performance capabilities:
-
Industrial Process Control:
The IMDSI15 module is an ideal choice for applications requiring the monitoring of on/off signals in process control systems. It can be used to collect signals from safety interlocks, limit switches, and other devices that regulate key equipment such as pumps, valves, and conveyors.
-
Factory Automation:
In factory automation, the IMDSI15 is used to collect digital input signals from devices such as pushbuttons, limit switches, and proximity sensors. It enables efficient and real-time monitoring, ensuring that all processes are managed smoothly and efficiently.
-
SCADA and DCS Systems:
Integrated into SCADA (Supervisory Control and Data Acquisition) and DCS (Distributed Control Systems), the IMDSI15 module is a key component for ensuring real-time monitoring and control of critical industrial operations. It provides fast, accurate input signal detection, crucial for maintaining system uptime and reliability.
-
Energy and Utilities:
The IMDSI15 module is ideal for use in energy applications such as power plants, substations, and electrical grids, where monitoring of circuit breakers, status indicators, and safety switches is essential to ensure uninterrupted power flow.
-
Building Automation:
In building automation systems, the IMDSI15 module can be used to monitor various field devices like temperature sensors, door switches, and light control systems, contributing to energy efficiency and system optimization.
Product Advantages
The ABB Bailey IMDSI15 module offers several advantages that make it a top choice for industrial automation:
-
High Input Density:
The IMDSI15 module features 16 digital input channels in a compact design, offering high input density without sacrificing space. This is especially beneficial for systems requiring multiple inputs in a limited space.
-
Electrical Isolation:
The module provides electrical isolation between the input channels, protecting sensitive equipment from electrical surges and ensuring reliable operation in environments with high electrical noise.
-
Wide Temperature Range:
With a temperature range of -25°C to 60°C, the IMDSI15 can operate in harsh and extreme industrial environments, making it suitable for outdoor or temperature-sensitive applications.
-
High-Speed Signal Processing:
The IMDSI15 module is designed for fast signal processing, ensuring that real-time monitoring of digital inputs is accurate and immediate. This makes it a preferred choice for time-sensitive applications where response time is critical.
-
Compact and Robust Design:
With dimensions of 220 x 100 x 40 mm and weighing only 0.6 kg, the IMDSI15 module offers a compact design that can be easily integrated into DIN rail-mounted control systems, ensuring easy installation and maintenance.
Brand: ABB Bailey
ABB Bailey is a recognized leader in distributed control systems (DCS) and industrial automation solutions. With decades of experience, ABB Bailey provides high-performance systems for sectors such as energy, manufacturing, chemical, and utilities. Their products, including the INFI 90 series, are known for reliability, scalability, and flexibility in automating complex industrial processes. ABB Bailey’s solutions help improve operational efficiency, increase system uptime, and enable sustainable operations across various industries.
Series
The ABB Bailey IMDSI15 module is part of the INFI 90 series, a distributed control system designed for the industrial sector. The INFI 90 series provides high-performance I/O modules and controllers designed for industries that require precise, reliable, and efficient control over their operations. It integrates seamlessly with ABB Bailey’s INFI 90 DCS and is designed to meet the most demanding requirements of modern industrial applications.
Recommended Models in the Same or Related Series
| Model |
Description |
Input Type |
Channels |
Power Consumption |
Dimensions (mm) |
Weight (kg) |
| IMDSI16 |
Digital Input Slave Module |
24 V DC |
16 |
4.2 W |
220 x 100 x 40 |
0.6 |
| IMDSI17 |
High-Speed Digital Input Module |
24 V DC |
16 |
4.5 W |
220 x 100 x 40 |
0.65 |
| IMDSI18 |
Compact Digital Input Slave |
24 V DC |
8 |
3.8 W |
220 x 100 x 40 |
0.58 |
| IMDSI19 |
Multi-Channel Digital Input |
24 V DC |
32 |
5.0 W |
220 x 100 x 40 |
0.7 |
| IMDSI20 |
Dual-Channel Digital Input |
24 V DC |
8 |
3.5 W |
220 x 100 x 40 |
0.6 |
Recommended Popular Models from the Same Brand
| Model |
Description |
Dimensions (mm) |
Weight (kg) |
| IMCPM01 |
Basic model with essential I/O and communication |
140 × 190 × 120 |
1.4 |
| IMCPM02 |
Enhanced version with advanced processing power |
145 × 200 × 130 |
1.5 |
| IMCPM03 |
Compact design with improved performance for I/O |
130 × 180 × 110 |
1.3 |
| IMCPM04 |
High-performance model with additional redundancy |
150 × 210 × 140 |
1.7 |
| IMCPM05 |
Extended I/O capacity with optimized power usage |
160 × 220 × 150 |
1.8 |
