ABB Bailey IMCPM01 Configuration Port Module
Product Overview
The ABB Bailey IMCPM01 is a configuration port module designed for use within the INFI 90 Distributed Control System (DCS). It serves as a key interface between engineering workstations and the control system, allowing for configuration, diagnostics, and maintenance operations. Its robust design and dependable connectivity ensure uninterrupted communication for critical industrial processes.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | IMCPM01 |
| Function | Configuration Port Module |
| Compatible System | INFI 90 DCS |
| Dimensions (W×H×D) | 75 × 200 × 35 mm |
| Weight | 0.181 kg |
| Mounting Style | Rack-mounted |
| Power Supply | 24 V DC via backplane |
| Operating Temperature | –20 °C to +65 °C |
| Communication Interface | RS-232 Serial Port |
| LED Indicators | Power, Communication Status |
| Enclosure Protection | IP20 |
Applications
-
System Configuration: Enables precise and convenient setup of INFI 90 DCS nodes and parameters.
-
Diagnostics: Used for monitoring system health and isolating faults efficiently.
-
Maintenance Access: Facilitates firmware updates and other service functions via engineering tools.
-
Engineering Interface: Provides a direct port for interaction with configuration software and utilities.
Advantages
-
Robust Communication: Delivers stable RS-232 serial connectivity between control systems and engineering environments.
-
Compact & Modular: Its streamlined design supports modular installation in space-limited racks.
-
Industrial Durability: Operates reliably in a wide temperature range and industrial conditions.
-
Simple Integration: Easily fits into ABB Bailey’s INFI 90 framework with plug-and-play capability.
Brand
IMCPM01 is developed by ABB Bailey, a respected name in industrial automation known for dependable control and monitoring solutions for critical infrastructure.
Series
The product is a member of the INFI 90 series, ABB Bailey’s flagship distributed control system, recognized for its flexibility, modularity, and long lifecycle support.
Related Models in the INFI 90 Series
| Model | Function | Interface | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| IMCPM01 | Configuration Port Module | RS-232 | 75 × 200 × 35 | 0.181 |
| IMCPM02 | Enhanced Config Port Module | RS-232 | 75 × 200 × 35 | 0.190 |
| IMDER01 | Drive Communication Module | RS-232 | 75 × 200 × 35 | 0.210 |
| IMSPM01 | Serial Port Module | RS-232 | 75 × 200 × 35 | 0.200 |
| INICT13A | Network Interface Controller | Ethernet | 75 × 200 × 35 | 0.185 |
Popular ABB Bailey Models
| Model | Function | Interface | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| IMDSI12 | Digital Input Module | 24 V DC | 75 × 200 × 35 | 0.200 |
| IMASI23 | Analog Input Module | 4–20 mA | 75 × 200 × 35 | 0.215 |
| IMMFP12 | Multi-function Processor | High-speed bus | 75 × 200 × 35 | 0.240 |
| IMTCL01 | Time Controller Module | Internal RTC | 75 × 200 × 35 | 0.185 |
| INNIS01 | Network Interface Slave Module | Ethernet | 75 × 200 × 35 | 0.190 |
Product FAQ (10 Q&A)
Q1: What is the primary function of the IMCPM01 module?
A1: It provides a configuration and communication interface between the INFI 90 system and engineering workstations.
Q2: Is the IMCPM01 compatible with all INFI 90 controllers?
A2: Yes, it is designed specifically to support all standard INFI 90 DCS hardware.
Q3: What type of communication does IMCPM01 use?
A3: It uses an RS-232 serial interface for configuration and diagnostics.
Q4: How is the IMCPM01 powered?
A4: It receives 24V DC power through the backplane of the rack-mounted system.
Q5: Can IMCPM01 be hot-swapped during operation?
A5: No, for safety and system integrity, it should be inserted or removed during shutdown.
Q6: What LED indicators are present on the IMCPM01?
A6: It includes indicators for power and communication status.
Q7: What is the operational temperature range of this module?
A7: It operates reliably from –20 °C to +65 °C.
Q8: How does this module aid in system maintenance?
A8: It enables diagnostic access and system parameter adjustments during maintenance.
Q9: What software can be used with IMCPM01?
A9: It is compatible with ABB Bailey configuration and diagnostic software tools.
Q10: Is special training required to use this module?
A10: Basic familiarity with INFI 90 systems and configuration software is recommended.
