ABB Bailey IMASM02 Analog Input Submodule

Product Introduction

The ABB Bailey IMASM02 is a high-performance Analog Input Submodule designed for use with the Infi 90 series of automation systems. It serves as an integral part of ABB Bailey’s renowned process control solutions, providing reliable and precise conversion of analog signals to digital information for system processing.

This IMASM02 module features the ability to handle a variety of field instruments that transmit analog signals such as temperature sensors, pressure transmitters, level sensors, and flow meters. It is engineered to work seamlessly with ABB Bailey’s Infi 90 platform, known for its robust, scalable, and highly reliable control system that is widely used in industries such as chemical, oil and gas, power generation, and water treatment.

Designed for industrial automation, the IMASM02 is built to meet the most demanding environments. It offers excellent performance in terms of both accuracy and speed, ensuring that real-time data is processed and transmitted without delay.

Product Specifications

Applications

The ABB Bailey IMASM02 Analog Input Submodule is essential in applications where precise and reliable analog signal processing is critical for process control and automation. Some of its key applications include:

1. Process Control Systems: The module is often used in chemical processing plants, pharmaceutical manufacturing, and refineries to monitor and process signals from field instruments, ensuring optimal operational conditions.

2. Power Generation: In power plants, the IMASM02 is used to measure critical parameters such as pressure, flow, and temperature of equipment such as turbines, pumps, and compressors, thereby aiding in efficient energy production.

3. Oil and Gas: The IMASM02 is highly beneficial in the oil and gas industry, where it monitors signals from temperature sensors, pressure transmitters, and flow meters installed in pipelines, drilling rigs, and storage tanks.

4. Water Treatment: The module is used in water and wastewater treatment facilities to ensure smooth operation of systems by monitoring levels, flow rates, and chemical treatments with high accuracy.

5. HVAC Systems: It is deployed in HVAC applications to control and monitor temperature, pressure, and humidity, ensuring effective climate control in large facilities and industrial plants.

6. Industrial Automation: The IMASM02 serves a vital role in factory automation systems, collecting signals from sensors that monitor equipment health, machinery status, and process parameters for intelligent control.

Advantages

1. High Accuracy: With ±0.1% full scale accuracy, the IMASM02 ensures high precision in reading and converting analog signals, leading to more accurate process control.

2. Fast Signal Conversion: The 10 ms conversion time per channel allows the module to quickly process analog signals, making it ideal for real-time control systems that demand rapid data feedback.

3. Robust Design: The IMASM02 is designed for harsh industrial environments, with a wide operating temperature range of -40°C to +70°C and a rugged IP20 protection rating, ensuring reliable operation in diverse conditions.

4. Flexible Signal Handling: It supports multiple types of analog signals, including 4-20 mA and 0-10 V, making it compatible with a variety of industrial sensors.

5. Compact and Space-Efficient: The 200 x 150 x 80 mm dimensions and 1.2 kg weight make it easy to install in control panels or confined spaces, optimizing system design and minimizing footprint.

6. DIN Rail Mounting: The module is equipped with DIN rail mounting, a standard method for industrial control systems, ensuring a stable and secure installation process.

7. Seamless Integration with Infi 90: The IMASM02 integrates seamlessly into the Infi 90 series, ensuring smooth communication between modules for enhanced system performance.

8. Scalability: The module can be used in large-scale systems that require multiple analog input channels, offering scalability for complex industrial setups.

9. Reliable Power Supply: Operating on a 24 V DC power supply, it ensures energy-efficient performance, reducing the overall power consumption of control systems.

10. Easy Maintenance: With its compact design and durable build, the IMASM02 requires minimal maintenance and is easy to replace if necessary.

Brand Overview: ABB Bailey

ABB Bailey is a trusted name in the industrial automation sector, recognized for its high-performance products, particularly in the field of process automation. The Bailey Infi 90 series, including the IMASM02, is specifically designed to meet the needs of industries that require mission-critical control and high availability. ABB Bailey’s solutions are trusted across industries like oil and gas, power generation, and chemical manufacturing for their precision, reliability, and scalability.
