ABB AO810V2 (3BSE038415R1) — Product Overview
Brand: ABB
Series: S800 I/O (part of ABB’s modular, distributed process I/O system compatible with 800xA and AC 800M platforms)
Product Introduction
The AO810V2 module is a precision analog output I/O module used within ABB’s S800 framework. Designed to manage eight unipolar analog output channels (0…20 mA or 4…20 mA), it enables reliable command of external devices such as valves, actuators, or drives. Compact and self-monitored, it fits neatly into control racks while offering built-in diagnostics to ensure safety and uptime.
Product Parameters
| Parameter | Specification |
|---|---|
| Number of Output Channels | 8 (unipolar analog outputs) |
| Output Types | 0…20 mA or 4…20 mA selectable |
| Resolution | 14-bit (some sources say 16‑bit) |
| Accuracy | ±0.1 % of full scale |
| Load Resistance | ≤ 500 Ω (L1+), 250–850 Ω (L2+) |
| Update Cycle Time | ≤ 2 ms |
| Rise Time | ~0.35 ms (with 500 Ω load) |
| Self‑Diagnostics | Includes OSP alarm state-on-error, open-circuit detection, module/channel faults |
| Power Dissipation | ~2.3 W |
| ModuleBus Current (+5 V) | Max 70 mA |
| External 24 V Current | ~245 mA |
| Insulation Voltage | Rated 50 V; Dielectric tested at 500 V AC |
| Temperature Drift | Typ. 30 ppm/°C, Max 60 ppm/°C |
| Field Cable Max Length | Up to 600 m |
| Diagnostics LEDs | Fault, Run, Warning, OSP indicators |
| Operating Temp | 0 °C to +55 °C (some sources say –25 °C to +55 °C) |
| Storage Temp | –40 °C to +70 °C |
| Protection Class | IP20 |
| Dimensions (W × D × H) | ~45 mm × 102 mm × 119 mm |
| Weight | ~0.18–0.20 kg |
Product Applications
Ideal for high-precision analog control in:
-
Process industries—regulating valves, actuators, and control loops through 4…20 mA or 0…20 mA signals
-
Manufacturing automation—driving analog inputs of control equipment and pneumatic or motorized valves
-
Oil & gas / chemical sectors—where precise control and diagnostic awareness reduce downtime
-
Distributed I/O systems—especially in 800xA or AC 800M setups, offering modular expansion and signal integration
Product Advantages
-
Compact and efficient—8 accurate outputs in a small 45 mm module
-
Reliable diagnostics—cycle self-check, open-circuit alerts, error LEDs, and OSP (Output Safe Position) ensure safety and maintenance clarity
-
Wide compatibility—fits into S800 racks and pairs with TU810/TU830 termination units
-
Strong signal integrity—fast update rates (≤ 2 ms), great rise times, and high load capacity
-
Industrial toughness—IP20 rating, broad temperature range, and certified to CE / UL / ATEX (Zone 2) standards
Related Models (Same Series or Family)
| Model | Description | Key Specs |
|---|---|---|
| AO810V2 | 8-channel analog output module (this model) | 0…20 mA or 4…20 mA, 14-bit, 45 × 102 × 119 mm, 0.2 kg |
| AO820 | 4-channel analog output | ±20 mA / ±10 V outputs |
| AO845A | 8-channel analog output with HART and redundancy | Adds commun. flexibility and fail-safety |
| AO840 | High-density 16-channel analog output | More channels in same form factor |
| AO815 | Hazardous-area analog output module | ATEX/IECEx certified for safe zone use |
Other Popular ABB Models (Same Brand)
| Model | Type | Standout Feature |
|---|---|---|
| AI830A | Analog Input Module | For RTD and temperature signals |
| DI828 | Digital Input Module | Class field high-voltage inputs with isolation |
| DO828 | Digital Output Module | Multiple relay outputs; isolated channels |
| AI845 | Analog Input Module | HART-enabled analog input for process instruments |
| AO820V2 | Analog Output Module | Upgraded AO820 with better compatibility and resolution |
Frequently Asked Questions (QA)
Q1: How many output channels are on the AO810V2?
A1: Eight unipolar analog output channels.
Q2: What output ranges can it handle?
A2: You can choose between 0…20 mA or 4…20 mA signaling.
Q3: Is it precise enough for fine control?
A3: Yes. It offers 14‑bit resolution and accuracy of ±0.1 % full scale.
Q4: Does it include diagnostics in case of failure?
A4: Absolutely—the module runs self-checks and reports errors via LEDs and OSP function for safety.
Q5: How fast are updates?
A5: The update cycle is ≤ 2 ms, with rise times around 0.35 ms at 500 Ω.
Q6: What environmental range can it handle?
A6: Operates between 0 °C and +55 °C and stores between –40 °C and +70 °C.
Q7: How big is the module physically?
A7: About 45 × 102 × 119 mm, weighing around 0.2 kg.
Q8: Is it safe for industrial environments?
A8: Yes—it’s IP20 rated, CE/UL certified, and designed for Zone 2/Div2 hazardous areas.
Q9: Can it drive heavy loads or long cables?
A9: Yes—it supports loads up to 500–850 Ω and cable runs up to 600 m.
Q10: What system does it integrate with?
A10: It connects with ABB’s 800xA and AC 800M control systems, via S800 racks and appropriate termination units.
