Product Overview
The ABB ACS800-01-0135-3 (3AUA0000015036) Frequency Converter is a high-performance industrial AC drive designed for demanding motor control applications that require high power output, precise speed regulation, and reliable long-term operation.
As part of the ABB ACS800 industrial drive family, the ACS800-01-0135-3 provides advanced motor control performance for heavy-duty industrial equipment. It is engineered to deliver stable torque control, excellent dynamic response, and efficient motor operation in complex automation environments.
The ACS800-01-0135-3 is designed for 110 kW motor applications and is widely used in industrial systems including pumps, fans, compressors, conveyors, mixers, extruders, and process machinery.
With dimensions of 880 x 300 x 399 mm and a weight of 67 kg, this frequency converter features a robust R6 frame structure suitable for high-power industrial installations requiring reliable performance and efficient heat management.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | ABB |
| Model | ACS800-01-0135-3 |
| Part Number | 3AUA0000015036 |
| Product Type | Frequency Converter |
| Series | ACS800 |
| Drive Type | Industrial AC Drive |
| Rated Power | 110 kW |
| Rated Output Current | 225 A |
| Input Voltage | 380–415 V AC |
| Phase | Three Phase |
| Frequency Range | 48–63 Hz |
| Control Technology | Direct Torque Control (DTC) |
| Installation Type | Wall Mounted |
| Frame Size | R6 |
| Protection Class | IP21 |
| Dimensions | 880 x 300 x 399 mm |
| Weight | 67 kg |
| Application | Industrial Motor Control |
Product Features
High-Power Motor Control Capability
The ABB ACS800-01-0135-3 provides reliable control for high-power industrial motors used in continuous production environments.
Key advantages:
- 110 kW motor control capability
- High current output performance
- Accurate speed regulation
- Excellent torque response
- Stable operation under changing loads
The drive is suitable for applications where motor reliability and production efficiency are critical.
Advanced Direct Torque Control Technology
The ACS800-01-0135-3 utilizes advanced motor control technology to provide fast and accurate control performance.
Main benefits:
- Rapid torque response
- Precise motor control
- Smooth acceleration and deceleration
- Excellent low-speed operation
- Improved system stability
This allows the drive to maintain reliable motor operation even during sudden load changes.
Robust Industrial Design
The frequency converter is designed for demanding industrial environments.
Design advantages:
- Strong mechanical structure
- Efficient cooling performance
- Reliable continuous operation
- Flexible installation options
- Suitable for automation systems
The compact R6 frame design provides a balance between high output performance and installation efficiency.
Energy-Efficient Operation
The ACS800-01-0135-3 helps optimize energy consumption by adjusting motor speed according to actual operating requirements.
Energy-saving benefits:
- Reduced unnecessary power usage
- Improved motor efficiency
- Lower mechanical stress
- Better process control
- Reduced operating costs
Variable speed control is especially useful for applications with changing load conditions.
Working Principle
The ABB ACS800-01-0135-3 converts fixed-frequency AC input power into adjustable-frequency AC output power to control motor speed and torque.
Operating process:
- Three-phase AC power enters the frequency converter.
- The rectifier converts AC voltage into DC voltage.
- The DC bus stores and stabilizes electrical energy.
- The inverter converts DC power into adjustable AC output.
- The motor receives controlled voltage and frequency.
- Motor speed and torque are adjusted according to application requirements.
This process enables efficient and precise motor control in industrial systems.
Industrial Applications
Pump Applications
The ACS800-01-0135-3 is suitable for large industrial pumping systems.
Typical applications:
- Water treatment equipment
- Industrial circulation pumps
- Cooling systems
- Process pumps
Benefits:
- Smooth startup performance
- Accurate flow control
- Reduced energy consumption
- Improved equipment reliability
Fan and Ventilation Systems
The frequency converter provides efficient speed control for large fan systems.
Applications:
- Industrial ventilation
- Cooling fans
- Exhaust systems
- Air handling equipment
Advantages:
- Adjustable airflow
- Stable operation
- Reduced energy consumption
- Extended equipment lifetime
Conveyor Systems
The ACS800-01-0135-3 provides reliable speed regulation for industrial conveyors.
Applications:
- Manufacturing lines
- Material handling systems
- Heavy-duty conveyors
- Production equipment
Benefits:
- Smooth acceleration
- Accurate speed control
- Reduced mechanical impact
- Improved production stability
Compressor Control
The frequency converter is widely used in industrial compressor applications.
Applications:
- Air compressors
- Process compressors
- Industrial machinery
Advantages:
- Stable pressure control
- Improved efficiency
- Reduced motor stress
- Reliable continuous operation
Installation Guide
Installation Preparation
Before installation, confirm:
- Correct frequency converter model
- Compatible motor specifications
- Proper power supply
- Suitable installation environment
- Reliable grounding system
- Adequate ventilation space
Step 1: Installation Location Selection
Choose an installation location with:
- Good ventilation
- Suitable operating temperature
- Low dust environment
- Protection from moisture
- Enough maintenance space
Install the drive vertically to ensure proper cooling.
Step 2: Mechanical Installation
Installation procedure:
- Place the frequency converter on the mounting surface.
- Secure the unit firmly.
- Confirm installation stability.
- Ensure cooling openings remain clear.
Step 3: Power Connection
Connect:
- Three-phase input power
- Motor output terminals
- Protective grounding cable
Check all connections carefully before startup.
Step 4: Control Wiring
Connect:
- Start and stop signals
- Speed reference signals
- Digital inputs
- Analog inputs
- Communication connections
Separate control wiring from power cables to reduce interference.
Step 5: Parameter Configuration
Configure essential parameters:
- Motor rated voltage
- Motor rated current
- Motor speed
- Motor frequency
- Acceleration time
- Deceleration time
- Control mode
Correct parameter settings ensure stable operation.
Step 6: Commissioning
Perform:
- Wiring inspection
- Power-up test
- Motor rotation check
- Parameter verification
- Load testing
- Fault monitoring
Confirm normal operation before placing the system into service.
Fault Diagnosis and Troubleshooting
Drive Cannot Start
Possible Causes
- Incorrect power connection
- Missing control command
- Incorrect parameters
- Control wiring failure
Solutions
- Check incoming power
- Verify start signals
- Review parameter settings
- Inspect control wiring
Overcurrent Fault
Possible Causes
- Motor overload
- Short circuit
- Incorrect motor parameters
- Mechanical blockage
Solutions
- Check motor condition
- Inspect motor cables
- Verify motor settings
- Reduce excessive load
Overvoltage Fault
Possible Causes
- Deceleration time too short
- Regenerative energy from load
- Incorrect braking settings
Solutions
- Increase deceleration time
- Adjust braking parameters
- Check load characteristics
Overheating Fault
Possible Causes
- Poor ventilation
- Cooling fan failure
- Excessive load
- High ambient temperature
Solutions
- Improve airflow
- Check cooling system
- Clean ventilation areas
- Reduce overload operation
Communication Fault
Possible Causes
- Incorrect communication settings
- Damaged cables
- Network configuration problems
Solutions
- Check communication parameters
- Inspect cables
- Verify control system configuration
Maintenance Recommendations
To maintain reliable operation:
- Clean cooling passages regularly
- Inspect electrical terminals
- Check cooling fan operation
- Monitor operating temperature
- Review fault history
- Verify parameter settings
Regular maintenance improves reliability and extends the service life of the frequency converter.
Key Advantages
High Power Output
Provides reliable performance for 110 kW industrial motor applications.
Strong Current Capability
Supports high-current motor control requirements.
Advanced Motor Control
Provides accurate torque and speed regulation.
Industrial Reliability
Designed for continuous-duty automation applications.
Flexible Installation
Suitable for various industrial control systems.
Technical FAQs
What is ABB ACS800-01-0135-3?
The ABB ACS800-01-0135-3 is an industrial frequency converter designed for controlling high-power AC motors.
What is the part number?
The part number is 3AUA0000015036.
What is the rated power?
The rated power is 110 kW.
What is the rated output current?
The rated output current is 225 A.
What are the dimensions?
The dimensions are 880 x 300 x 399 mm.
What is the weight?
The weight is 67 kg.
Conclusion
The ABB ACS800-01-0135-3 3AUA0000015036 Frequency Converter is a reliable industrial AC drive designed for high-power motor control, efficient operation, and long-term industrial performance.
With its 110 kW power capacity, 225 A output capability, advanced torque control technology, robust construction, and flexible installation design, it provides an excellent solution for pumps, fans, compressors, conveyors, and other demanding industrial automation applications.
The ACS800-01-0135-3 helps improve energy efficiency, enhance production stability, reduce mechanical stress, and maintain reliable operation in modern industrial environments.
