Product Overview — 5SHY 3545 L0014 (3BHE023784R0001) IGCT Module
Brand: ABB
Series: 5SHY — High-Power Press-Pack IGCT Modules
Product Introduction
The 5SHY 3545 L0014, part number 3BHE023784R0001, is a high-power Insulated Gate Commutated Thyristor (IGCT) module in a robust press-pack design. Engineered for demanding industrial applications, it delivers exceptional voltage and current performance in a compact form. This module achieves efficient power switching with minimal losses, supports SIL-2 safety levels, and is especially suited for reliability-critical systems like rail traction, HVDC converters, megadrives, wind turbines, and marine propulsion. A fiber-optic status output adds diagnostic insight, although often unused in standard drive setups.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 5SHY 3545 L0014 (3BHE023784R0001) |
| Device Type | Press-Pack IGCT Module |
| Rated Voltage | 4500 V |
| Nominal Current | ~4000 A at 25 °C |
| Peak Surge Current | ~8000 A (10 ms) |
| Switching Frequency | Up to 500 Hz |
| Thermal Resistance (J‑C) | ~0.012 K/W |
| Insulation Voltage | ~10 kV AC/min |
| Dimensions (L × W × H) | ~190 × 140 × 38 mm |
| Weight | ~2.3 kg (2.3 kilograms) |
| Housing Design | Press-pack with fiber-optic status (unused in ACS 6000) |
| Operating Temperature (Junction) | –40 °C to +125 °C |
| Certifications | UL 1557, IEC 60747‑9, SIL‑2 IEC 61508 compliant, marine-grade suitability |
| Origin | Switzerland |
Applications
This module thrives in high-power conversion and control systems:
-
Rail traction: High-speed trains and regenerative braking systems
-
HVDC converters: Grid interconnection and power balancing
-
Industrial megadrives: Rolling mills, compressors, heavy-duty motors requiring precise torque control
-
Renewable energy: Multi-megawatt wind turbine converters and STATCOM systems
-
Marine propulsion: IGBT-based electric drives in challenging marine environments
Its rugged press-pack design, efficient switching, and fault-tolerant behavior make it a top pick for systems requiring reliability under stress.
Key Advantages
-
High switching efficiency: Ultra-low conduction and switching losses (~15–20% improvement on previous generations)
-
Fault resilience: Press-pack structure fails short, enabling fault-tolerant configurations in converters
-
Superior thermal management: Supports liquid cooling and handles extreme thermal flux, up to 450 W/cm²
-
Compact and robust: Bond-wire-free design ensures longevity in cyclic and vibration-heavy environments
-
Easy integration: Low-inductance copper interfaces and compatibility with existing gate driver systems streamline adoption
Related Modules (Same Family)
| Model | Details |
|---|---|
| 5SHY 3545 L0014 | Current press-pack IGCT module (this model) |
| 5SHY 3545 L0004 | Slightly lower current rating variant |
| 5SHY 5045 L0020 | Next-gen successor with improved dv/dt handling |
| HVD800 Gate Unit | Companion driver module for these press-pack IGCTs |
| 5SDF2565H0001 | Press-pack diode module for NPC applications |
Other Popular ABB High-Power Modules
| Model | Description |
|---|---|
| ACS6080 | Integrated drive cabinet using 5SHY modules |
| SSSC‑300 | Static synchronous compensator with 5SHY |
| Press-pack Diode | Companion devices for IGCT power stacks |
| HVD800 | Gate driver module for IGCT control |
| 5SHY™ Variants | Broader family of high-power IGCT modules |
FAQs (QA Format)
Q1: What makes this module stand out?
A1: Its press-pack IGCT design ensures high power capacity, low loss switching, and rugged reliability.
Q2: What are its key ratings?
A2: Rated at 4500 V, nominal 4000 A, peak 8000 A, and up to 500 Hz switching frequency.
Q3: How big and heavy is it?
A3: Approximately 190×140×38 mm and 2.3 kg.
Q4: What operating temperature range does it support?
A4: Junction temperature from –40 °C to +125 °C; active under heavy cycling seen in rail and industrial uses.
Q5: How does it fare in harsh conditions?
A5: Press-pack design and thermal resilience ensure robustness in vibration and thermal cycling scenarios.
Q6: What fault protection does it offer?
A6: It fails safe into a short circuit, enabling series redundancy without uncontrolled breakdowns.
Q7: How is thermal load managed?
A7: Built for liquid-cooled setups and effective heat dissipation up to 450 W/cm².
Q8: Is it easy to integrate?
A8: Yes—features ready-for-use copper interfaces and compatibility with existing gate driver systems.
Q9: What safety standards does it meet?
A9: UL 1557, IEC 60747‑9, SIL‑2 (IEC 61508), and marine application certifications.
Q10: What upgrade options exist in this family?
A10: Variants supporting higher current (5045 L0020), or combinations with gate drivers (HVD800) and diodes are available.
