📘 Product Overview: 5SHY3545L0010 (3BHB013088R0001)
Product Introduction
The 5SHY3545L0010 is an advanced IGBT gate driver unit designed for high-reliability, medium-to-high-voltage power electronics applications. It builds upon the foundation of earlier driver units, with enhanced diagnostics, fault detection, and thermal handling. The driver ensures precise gate control for IGBT or MOSFET modules, enabling optimized switching performance in demanding environments. It is intended for integration into industrial drives, renewable energy inverters, railway traction, and other high-power converter systems.
This version (0010) features improved fault-reporting, refined insulation between control and power stages, and a more compact layout to reduce parasitic inductance. It is designed for both retrofit and new equipment.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 5SHY3545L0010 |
| Internal Code | 3BHB013088R0001 |
| Product Type | High-voltage IGBT Gate Driver Unit |
| Maximum Application Voltage | Up to 4500 V |
| Gate Drive Voltage | ±15 V (typical) |
| Control Supply Voltage | 15 V DC |
| Maximum Operating Temperature | –40 °C to +85 °C |
| Switching Frequency Range | DC to 2 kHz |
| Isolation Voltage | >10 kV |
| Diagnostics / Protection Features | Desaturation detection, over-temp cut-off, soft-off, under-voltage lockout |
| Communication Interface | Fiber-optic + auxiliary logic-level fault signaling |
| Dimensions (Length × Width × Height) | 233 mm × 115 mm × 35 mm |
| Weight | 1.55 kg |
| Cooling Method | Natural convection; optional forced-air via fan or ducting |
| Mounting | Panel mount (4-point fixing) |
| Compliance | CE, RoHS, UL-type insulation class |
| Designed For Modules | IGBT modules such as those from 5SNA or equivalent families |
Product Applications
-
Industrial Motor Drives
Used in medium-voltage drives for pumps, compressors, rolling mills, where reliable IGBT switching is critical. -
Renewable Energy Inverters
Applies to large-scale solar, wind turbine converters needing tight switching control and safety isolation. -
Rail Traction Systems
Powering inverters in locomotive / EMU/METRO traction, demanding robust diagnostics and high reliability. -
Marine & Ship Propulsion
Enables drive control in electric propulsion, generators, etc., under vibration and harsh environmental stress. -
Heavy Duty Power Conversion
In metallurgy, mining, oil & gas, or grid intertie converters where high-voltage, high-current makes gate driver reliability vital.
Product Advantages
-
Improved Diagnostic Feedback
Early detection of faults (over-temperature, desaturation, under-voltage) allows preventative maintenance and minimizes downtime. -
High Isolation Safety
10 kV isolation ensures safety between control circuits and high-voltage power stage; reduces risk of electrical hazard.
-
Excellent Thermal Stability
Wide operating temperature range (–40 °C to +85 °C), even under switching losses; design manages thermal stress well. -
Reduced Parasitics
Compact layout and optimized parasitic inductance reduce switching overshoot, leading to lower electromagnetic interference. -
Robust Build & Long Life
Rugged components, quality insulation, protected against environmental stresses (vibration, humidity) → high MTBF.
Brand & Series
-
Brand: ABB
-
Series: High-Voltage IGBT Gate Driver Series (e.g. “5SHY” family)
-
Category: Gate Drivers / Gate Driver Units
🔁 Related Models (Same Series or Relevant)
Below are 5 models in the same series or very closely related in function, with comparative parameters.
| Model | Gate Drive Voltage | Max Application Voltage | Dimensions (mm) | Weight (kg) | Key Distinguishing Feature |
|---|---|---|---|---|---|
| 5SHY3545L0009 | ±15 V | 4500 V | 233 × 115 × 35 | 1.50 | Baseline version (without enhanced diagnostics) |
| 5SHY3545L0011 | ±15 V | 4500 V | 230 × 115 × 35 | 1.60 | Adds fiber-optic remote monitoring module |
| 5SHY3545L0008 | ±15 V | 3300 V | 210 × 110 × 35 | 1.30 | Lower voltage version, for medium-voltage use |
| 5SHX1060H0001 | ±15 V | 4500 V | 250 × 120 × 40 | 1.80 | Integrated protection logic and higher switching frequency |
| 5SDF1045H0001 | ±15 V | 4500 V | 240 × 100 × 35 | 1.60 | Enhanced cooling design, better mounting flexibility |
🔝 Popular Models (Same Brand)
Here are 5 other well-known products from ABB, valued in the field; though not always exactly same series, they are “popular” for similar applications.
| Model | Product Type | Voltage Rating | Dimensions (mm) | Weight (kg) | Prominent Uses / Key Notes |
|---|---|---|---|---|---|
| 5SNA1500E330305 | High-current IGBT Module | 3300 V | 180 × 140 × 40 | 2.50 | Used in traction inverters and heavy drives |
| 5SDF1060H0001 | Gate Driver Unit | 4500 V | 250 × 110 × 40 | 1.70 | Similar driver with advanced optical communication |
| 5SHY4045L0001 | Gate Driver | 4500 V | 220 × 115 × 35 | 1.40 | Older gen gate driver, well-proven in many setups |
| 5STP33Q2800 | Phase-Control Thyristor Module | 2800 V | 190 × 90 × 30 | 1.20 | For controlled rectification, less switching applications |
| 5SNA1200E330306 | IGBT Module | 3300 V | 200 × 150 × 50 | 3.00 | For very high current, industrial inverter applications |
❓ FAQ (Q&A)
Q1: What is the purpose of the 5SHY3545L0010?
A1: It acts as a gate driver, controlling IGBT modules by supplying gate voltage, isolating power/control stages, and protecting the module under fault conditions.
Q2: What is the maximum voltage this driver can handle?
A2: It is designed for application voltages up to 4500 V at the power side.
Q3: What specific diagnostics are included?
A3: Includes desaturation detection (to catch IGBT short or overcurrent), over-temperature cutoff, under-voltage lockout, and fault signaling via logic output plus fiber-optic.
Q4: What kind of environments can it operate in?
A4: From –40 °C to +85 °C, suitable for industrial, marine, railway or renewable energy settings with possible forced cooling if needed.
Q5: Is there any special requirement for mounting or cooling?
A5: It is panel-mounted with four fixing points; natural convection is acceptable under moderate load, but forced air or proper airflow is advised when ambient temperatures are high or switching losses are greater.
Q6: How does it compare to older model 5SHY3545L0009?
A6: The 0010 version adds improved diagnostics, slightly increased isolation robustness, and small design tweaks to reduce internal parasitic inductance.
Q7: What is the weight and size?
A7: Approximate dimensions are 233 × 115 × 35 mm, weight about 1.55 kg.
Q8: How is communication / fault reporting handled?
A8: It uses fiber-optic interfaces for isolation and reliability, along with auxiliary logic-level fault outputs for integration into control systems.
Q9: What standards of safety or compliance are met?
A9: Designed to meet CE and RoHS environmental and safety regulation standards; insulation is of high class to support >10 kV isolation.
Q10: What are typical application frequency limits?
A10: It is rated for switching up to about 2 kHz, though practical limit may be lower depending on thermal management and load switching losses.
