Product Overview
The ABB 560PSU01 R0002 1KGT006600R0002 RTU560 Power Supply Unit is a power supply component for ABB RTU560 remote terminal unit systems. It supplies the required operating power to the associated RTU560 system components, allowing processing, communication, and I/O modules to operate as part of the remote automation installation.
In a typical substation or utility automation cabinet, the power supply unit is installed as part of the RTU hardware architecture. It works upstream of the RTU processing and I/O components, converting and distributing the available supply to the system’s internal operating circuits.
Stable power is essential for RTU applications because a power interruption can affect multiple functions at the same time. An abnormal power supply condition may appear as processor failure, communication loss, I/O malfunction, or unexpected system restart. For this reason, troubleshooting should begin by checking the incoming supply, power connections, and power-supply status before replacing other RTU modules.
The 560PSU01 R0002 is suitable for RTU installations where continuous operation of remote monitoring and control equipment is required. During replacement, engineers should verify the complete RTU560 hardware configuration, supply requirements, wiring, and downstream module status.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 560PSU01 R0002 |
| Part Number | 1KGT006600R0002 |
| Product Family | ABB RTU560 |
| Product Type | Power Supply Unit |
| Primary Function | RTU560 system power supply |
| System Role | RTU power supply interface |
| Application | Substation automation, utility automation, and remote monitoring |
| Dimensions | 160 × 40 × 100 mm |
| Weight | 0.6 kg |
Product Features
- ABB RTU560 power supply component
- Supplies operating power for associated RTU560 system hardware
- Supports RTU processing, communication, and I/O operation
- Suitable for substation and utility automation systems
- Intended for integration within RTU560 control cabinets
- Supports centralized remote monitoring and control infrastructure
- Provides the power interface between the site supply and RTU equipment
- Useful for remote electrical automation installations
- Power status can be considered during system-level troubleshooting
- Suitable for maintenance and replacement of RTU560 power supply assemblies
Working Principle
The 560PSU01 R0002 forms the power entry and distribution stage of an RTU560 installation. The available electrical supply is connected to the power supply unit, which conditions and supplies the operating power required by the connected RTU560 system components.
The downstream RTU hardware uses this supplied power for processing, communication, and I/O functions. If the power supply is interrupted or becomes unstable, several RTU functions can be affected simultaneously.
Incoming Power → 560PSU01 Power Supply Unit → RTU560 Backplane / System Hardware → Processing / Communication / I/O
When diagnosing an RTU that has stopped operating, engineers should first confirm incoming power and the power supply connection. If the supply stage is normal, troubleshooting can then move toward the processor, communication modules, I/O modules, and field equipment.
Role in an ABB RTU560 Power Architecture
The 560PSU01 occupies the power-supply layer of the RTU560 architecture. It supports the operating power requirements of the RTU system rather than directly processing field signals or performing communication functions.
Site Power → 560PSU01 → RTU560 System Hardware → Processing / Communication / I/O → Field Equipment
| System Element | Function |
|---|---|
| Site Power Supply | Provides the electrical source for the RTU installation |
| 560PSU01 | Supplies operating power to the RTU560 system |
| RTU560 Processing Unit | Processes RTU data and executes configured functions |
| RTU560 Communication Unit | Handles communication with remote or supervisory systems |
| RTU560 I/O Modules | Interfaces with field measurements and control signals |
| Field Equipment | Provides measurements, status information, and controlled devices |
| SCADA / Control Center | Supervises the remote installation |
Industrial Applications
| Application | Typical Use |
|---|---|
| Electrical Substations | Powering RTU hardware used for substation monitoring and control |
| Power Distribution | Supporting remote terminal units at distribution sites |
| Utility Automation | Supplying remote monitoring and control equipment |
| Grid Monitoring | Maintaining operating power for remote electrical data acquisition |
| Substation SCADA | Supporting RTU systems connected to supervisory platforms |
| Remote Infrastructure | Powering unattended or geographically distributed RTU installations |
| Industrial Power Systems | Supporting remote electrical monitoring and control |
| Energy Management | Maintaining RTU hardware used for centralized energy supervision |
Installation and Maintenance
- Verify the complete 560PSU01 R0002 / 1KGT006600R0002 identification before replacement.
- Confirm the RTU560 system configuration and the role of the existing power supply unit.
- Check the site’s incoming supply before disconnecting the power supply.
- Follow the applicable electrical isolation and maintenance procedures.
- Record existing power connections and terminal assignments before removal.
- Inspect power wiring and terminals for looseness, overheating, oxidation, or physical damage.
- Check the condition of associated RTU560 modules and their connections.
- Install the replacement unit according to the existing RTU560 hardware arrangement.
- Verify power connections before energizing the system.
- Check the RTU560 processor, communication, and I/O status after power-up.
- Confirm that remote communication and field data acquisition have returned to normal.
- Record the replacement information and power-system test results for future maintenance.
Related Components
| Component | Function |
|---|---|
| ABB RTU560 | Remote terminal unit platform |
| RTU560 Processing Unit | Executes RTU processing and control functions |
| RTU560 Communication Unit | Provides communication with external systems |
| RTU560 I/O Modules | Interfaces with field signals and equipment |
| RTU560 Backplane / System Interface | Connects and supports RTU system modules |
| Site Power Supply | Provides the incoming electrical source |
| SCADA System | Supervises remote RTU installations |
| Substation Equipment | Provides field measurements and control points |
Recommended Related Models
| Model / Product Family | Product Type | Typical Application |
|---|---|---|
| 560PSU01 R0002 | RTU560 Power Supply Unit | RTU system power supply |
| 1KGT006600R0002 | RTU560 Power Supply Unit Part Number | Power supply replacement |
| ABB RTU560 Series | Remote Terminal Unit | Substation and utility automation |
| RTU560 Power Supply Units | Power Supply Components | RTU system power distribution |
| RTU560 Processing Units | RTU Processing Components | Data processing and control |
| RTU560 Communication Units | Communication Components | Remote and supervisory communication |
| RTU560 I/O Modules | Remote I/O Components | Field signal acquisition and control |
| RTU560 System Components | RTU Hardware | Complete remote automation systems |
Key Advantages
- Supports operating power for ABB RTU560 systems
- Integrates directly into RTU560 remote automation architectures
- Suitable for substation and utility applications
- Supports continuous operation of connected RTU hardware
- Simplifies power-stage troubleshooting within the RTU system
- Suitable for maintenance and replacement of RTU560 power supply components
Technical FAQs
What is the function of the 560PSU01 in an RTU560 system?
The 560PSU01 supplies operating power to the associated RTU560 system hardware. It supports the processor, communication, and I/O sections so that the complete RTU can perform its configured monitoring and control functions.
Why can a power supply problem cause communication and I/O faults at the same time?
The power supply is upstream of several RTU560 functional modules. If its output is interrupted or unstable, the processor, communication equipment, and I/O modules can be affected simultaneously, creating multiple apparent system faults.
How should an engineer troubleshoot an RTU560 that does not start after maintenance?
Start with the incoming electrical supply and verify the power connections to the 560PSU01. Then check the power supply status and the operating status of the processor, communication units, and I/O modules. This sequence helps distinguish a system-wide power problem from a fault in an individual downstream module.
What should be checked before replacing the 560PSU01 R0002?
Verify the complete part number, RTU560 hardware configuration, incoming supply, power wiring, terminal assignments, and associated system modules. After replacement, the RTU should be powered up under controlled conditions and the processor, communication, I/O, and remote SCADA functions should be checked.
